Smart Shutoff Valves
Intelligent water control and leak prevention systems.
All Variants & Sizes
Both models are available through Al Taqa Technical. Contact us for pricing, sizing guidance, and technical support tailored to your project.
Wired M-Bus Shutoff Valve — DN15 to DN40
Motorised ball valve with integrated M-Bus communication for remote open/close control and status monitoring. Designed for residential and light-commercial applications up to DN40. Pairs with M-Bus gateways and head-end software for automated leak response and tenant billing. DN100 size available on request.
| Valve Type | Motorised ball valve |
|---|---|
| Nominal Diameter | DN15 / DN20 / DN25 / DN32 / DN40 (DN100 on request) |
| Communication | Wired M-Bus (EN 13757) |
| Actuation | Electric motor, full stroke < 5 seconds |
| Power Supply | 24V DC (via M-Bus bus power) |
| Operating Pressure | Up to 16 bar (PN16) |
| Body Material | Brass |
| Protection Rating | IP65 |
| Fail-Safe Position | Holds last position on power loss |
| Mounting | Inline; horizontal or vertical |
Wired M-Bus Shutoff Valve — DN50 and Above
Heavy-duty motorised ball valve with M-Bus interface for large-diameter pipework from DN50 upward. Built for commercial, industrial, and district cooling applications where high flow rates and robust construction are required. DN100 size available — price on request.
| Valve Type | Motorised ball valve (heavy duty) |
|---|---|
| Nominal Diameter | DN50 / DN65 / DN80 / DN100 (price on request) |
| Communication | Wired M-Bus (EN 13757) |
| Actuation | Electric motor, full stroke < 10 seconds |
| Power Supply | 24V DC / 230V AC (model dependent) |
| Operating Pressure | Up to 16 bar (PN16) |
| Body Material | Brass / Stainless steel |
| Protection Rating | IP65 |
| Fail-Safe Position | Configurable (normally open / normally closed) |
| Mounting | Inline; flanged or threaded connection |
LoRaWAN Shutoff Valve — DN15 to DN80 (230V / 50Hz)
Wireless motorised shutoff valve with integrated LoRaWAN connectivity for long-range, battery-free remote control without M-Bus cabling. Powered at 230V / 50Hz, it covers DN15 to DN80 and integrates with any LoRaWAN network server for automated leak isolation and facility management. DN100 available on request.
| Valve Type | Motorised ball valve |
|---|---|
| Nominal Diameter | DN15 / DN20 / DN25 / DN32 / DN40 / DN50 / DN65 / DN80 (DN100 on request) |
| Communication | LoRaWAN Class A/C (EU868 / AS923) |
| Actuation | Electric motor, full stroke < 10 seconds |
| Power Supply | 230V AC / 50Hz |
| Operating Pressure | Up to 16 bar (PN16) |
| Body Material | Brass / Stainless steel |
| Protection Rating | IP65 |
| Fail-Safe Position | Configurable (normally open / normally closed) |
| LoRaWAN Range | Up to 5 km line-of-sight; gateway dependent |
- Commercial Buildings
- Hospitality
- Industrial Facilities
- Utilities
Compatible with leading BMS platforms including Johnson Controls, Schneider Electric, Honeywell, and Tridium for a unified view of your facility's energy performance.
Request a Quote for Smart Shutoff Valves
Share your project details and our engineering team will respond with pricing, technical guidance, and datasheets tailored to your facility.
